Rogers RO4350B™ is a glass-reinforced hydrocarbon/ceramic laminate offering balanced RF performance (Dk=3.48, Df=0.0037 @ 10 GHz) and FR-4 process compatibility. Its low moisture absorption (0.06%), thermal stability, and halogen-free design make it ideal for cost-sensitive wireless applications, including 5G/Wi-Fi antennas, automotive radar, and IoT devices.
| Material | Rogers 4350B |
|---|---|
| Board Thickness | 1.524mm（60mil） |
| Copper Thickness | 1/1oz（35um） |
| Quanlity Standard | GJB362B |
| Dielectric Constant (Dk) | 3.48 @10GHz |
| Dissipation Factor (Df) | 0.0037 @10GH |
| Applications | |
| Surface Finish | ENIG 2u |
Rogers RO4350B™ High-Frequency Laminate Description
Rogers RO4350B™ is a glass-reinforced, hydrocarbon/ceramic thermoset laminate engineered to combine RF performance with FR-4 process compatibility. It bridges the gap between standard FR-4 and high-end RF materials, offering exceptional electrical stability and cost efficiency for wireless applications. Key properties include:
Optimized Dielectric Properties: Stable relative permittivity (Dk = 3.48 ±0.05 @ 10 GHz) and ultra-low loss tangent (Df = 0.0037 @ 10 GHz), minimizing signal loss.
FR-4 Process Compatibility: Compatible with standard multilayer PCB fabrication processes (drilling, plating, etching) and lead-free assembly, reducing manufacturing costs.
Thermal Reliability: Low Z-axis CTE (32 ppm/°C) and high thermal conductivity (0.69 W/m/K) prevent delamination during thermal cycling.
Flame-Retardant: UL 94 V-0 rated for safety-critical applications.
Moisture Resistance: Very low moisture absorption (0.06%), ensuring stable performance in humid environments.
Halogen-Free: Compliant with RoHS and IEC 61249-2-21 environmental standards.
Consistent Impedance Control: Tight Dk tolerance (±0.05) enables precise high-frequency signal integrity.
Primary Applications:
Wi-Fi routers/access points (2.4/5/6 GHz)
Cellular infrastructure (4G/5G antennas, small cells)
Automotive radar/sensors (24 GHz, 77 GHz)
IoT devices and RFID systems
Satellite communication terminals
General-purpose RF/microwave circuits
We offer a variety of high-frequency materials, including Rogers (e.g., RO4350B, RO5880), Taconic, and PTFE, depending on customer requirements.
Absolutely, we can provide detailed datasheets for review.
Our high-frequency PCBs can support frequencies up to 110 GHz, depending on the design and materials used.
We ensure precise impedance control through accurate stackup design, detailed impedance simulations, and advanced manufacturing processes.
Yes, we can combine materials like FR4 and high-frequency laminates for hybrid PCBs.
Restrictions mainly involve minimum trace width/spacing and material selection, depending on your design requirements.
We enhance thermal performance by using high thermal conductivity materials (e.g., metal-based PCBs) and optimizing copper thickness.
Thermal conductivity ranges from 0.2 W/m·K to 1.0 W/m·K, depending on the material.
ENIG/Gold Plating/Immersion Silver/Silver Plating/HASL/Gold finger/OSP/Nickel-palladium Gold/Resin plugging/Countersinking/ENIG+Hard Gold Plating/ImNi+ImTin/ENIG+OSP
ENIG is recommended due to its flat surface and excellent conductivity for high-frequency use.
We can produce high-frequency PCBs with layers ranging from 2 to 72.
Yes, we specialize in multilayer high-frequency PCBs and support hybrid stackup processes.
The thickness tolerance is ±0.05 mm, and the trace width tolerance is ±10%.
We perform impedance testing, RF performance testing, vacuum thermal testing, and more.
We achieve this by using high-quality materials, optimized manufacturing processes, and strict control of board thickness and other parameters.
Answer: Prototypes typically take 2–7 business days, while mass production takes 6–15 business days, depending on order volume and complexity.
High-frequency materials (e.g., Rogers) are more expensive, and higher layer counts increase complexity and cost.
We ensure reliability by using high-quality materials, rigorous testing, and optimized manufacturing processes.
Yes, our PCBs can endure temperatures up to 260°C and are suitable for harsh environments.
We use anti-static bags, vacuum packaging, and shockproof padding in the outer cartons for protection.
We provide air freight, express delivery, and sea shipping, depending on your needs, DHL is always prefered that ensure timely delivery through reliable logistics.
